APPENDIX 4C
CARBONARMOR® WALL REINFORCING SYSTEM
Chapter 4
Miscellaneous Structural Support Products
10” Masonry Block Wall
5
6
7
8
9
10
Unbalanced fill Height (ft.)
5
5.0
5.0
5.0
5.0
5.0
5.0
6
5.0
5.0
5.0
5.0
5.0
7
5.0
5.0
5.0
4.5
8
4.0
3.5
3.5
9
3.0
2.5
10
2.5
8” Concrete Wall
5
6
7
8
9
10
Unbalanced fill Height (ft.)
5
5.0
5.0
5.0
5.0
5.0
5.0
6
5.0
5.0
5.0
5.0
5.0
7
5.0
5.0
5.0
5.0
8
5.0
5.0
5.0
9
5.0
4.5
10
3.5
10” Concrete Wall
5
6
7
8
9
10
Unbalanced fill Height (ft.)
5
5.0
5.0
5.0
5.0
5.0
5.0
6
5.0
5.0
5.0
5.0
5.0
7
5.0
5.0
5.0
5.0
8
5.0
5.0
5.0
9
5.0
5.0
10
4.5
1.
Maximum recommended spacing from corners is 3 feet.
2.
Spacing could be less than listed in the above chart based on the condition of the wall and the severity of wall displacement.
